XZS Serices Planetary Servo Wheel

A 3D rendering of a mechanical assembly featuring a large blue wheel, a black gearbox with red mounting points, and visible bolts.

Additional information

Model	XZS125, XZS150, XZS165, XZS300, XZS95

Single Drive Wheel is a specialised gear system for applications in Automated Guided Vehicles (AGVs).One of the main functions of the Single Drive Wheel is deceleration, i.e. reducing the speed of the input shaft and increasing the torque of the output shaft. This principle is the same as gear reduction, but the Single Drive Wheel offers higher efficiency and a more compact construction. With the Single Drive Wheel, high output torques can be achieved, which is important for applications where high torque is required.The design of the Single Drive Wheel allows for high transmission efficiency and reduced energy losses. Due to its structural characteristics, the Single Drive Wheel can achieve high transmission efficiency in a relatively small space, which is ideal for equipment with limited space such as AGVs.

Flexible Partnership Options: We welcome OEM/ODM projects, bulk orders, and distribution inquiries. Our dedicated team is ready to assist you with tailored solutions and responsive support. Free samples are available upon request to ensure your complete satisfaction.

Product Description

Servo wheel system – its power core is from its servo-driven motor, which is able to continuously and steadily deliver strong power to drive the planetary gearbox to rotate accurately and precisely, ensuring the smoothness and efficiency of the whole transmission system.
The built-in planetary gear reducer converts the high-speed rotation of the motor to a smoother low-speed rotation in a delicate way, and in the process, realises the multiplication of torque, which gives servo wheel the same strong traction in low-speed operation.
In the choice of materials, we are even more excellence, the choice of polyurethane and other cutting-edge materials to build servo wheel, these materials not only have extraordinary wear resistance to ensure the durability of the gears, but also because of its excellent ground adhesion, for the AGV in a variety of complex and variable ground environment to provide a more stable and reliable driving support to ensure that the vehicle in any situation can be maintain excellent performance and performance in all circumstances.

Product Parameters

XZS series	XZS95	XZS125	XZS150	XZS165	XZS300
Outside diameter of wheel	120,140	150,160	180,200	220,250	350,380
Motor power	400W	400W	400W,750W	1500W	7500W
Motor voltage	48V	48V	48V	48V	72V
Polyurethane load-bearing	150KG,300KG	350KG,400KG	400KG,450KG	1120KG,1150KG	2500KG,3000KG
Maximum velocity	16.1-70.7M/min	20.2-88.3M/min	24.2-106M/min	29.6-129.5M/min	31.4-137.4M/min
Traction weight	579-612KG	434-459KG	386-408KG	1186-2751KG	5472-7817KG
